Horizontal Cryogenic Liquid Oxygen Pumping Liquid Pump With High Pressure Seal for Industry Gases Filling Stations Pompe
Product descriptions from the supplierProduct DescriptionCryogenic pump is the important equipment and the most complicated part from all unit, it is very important to have a reliable pump for the maintenance and operation. - Vacuum jacketed cold end helps minimize heat leak leaks and reduce produ......
Product descriptions from the supplier
Product Description
Cryogenic pump is the important equipment and the most complicated part from all unit, it is very important to have a reliable pump for the maintenance and operation.
- Vacuum jacketed cold end helps minimize heat leak leaks and reduce product loss
- Stainless steel drive housing for extended pump life
- Split drive end housing for easy maintenance access
- Monel suction strainer for oxygen compatibility (Customized)
- Grease lubricated, sealed-for-life bearings for extended operation
- Extended stem vacuum port with positive seal for improved vacuum integrity
- Intermediate purge connection allows for extended packing life
- Positive locking drive coupling for improved safety operation
- Stainless steel drive housing for extended pump life
- Split drive end housing for easy maintenance access
- Monel suction strainer for oxygen compatibility (Customized)
- Grease lubricated, sealed-for-life bearings for extended operation
- Extended stem vacuum port with positive seal for improved vacuum integrity
- Intermediate purge connection allows for extended packing life
- Positive locking drive coupling for improved safety operation
This pumps are used for the filling station.
and after-sale service
A control cabinet equipped with a HMI (man-machine interface) English language on HMI screen and Manual
Skid-Mounted Filling System including as below and the valve, Instrument will be installation and Commissioning in workshop /
1. HIGH PRESSURE PUMPS: Vertical reciprocating pump with vacuum jacketed cold end and grease lubricated crank drive Cold end materials are suited to pumping oxidizing gases such as liquid oxygen (LO2) and liquid nitrous oxide (LN2O). Discharge pressure up to 380bar. PD 3000 are typically used for 150, 200 or 300bar cylinder filling.
2. High pressure line control panels：
Available in two different execution:
* The Discharge Gas Control Panel (DGCP) for temperature and pressure control only
* The Buffer Skid for temperature, pressure, and buffer control
3. AMBIENT AIR VAPORIZERS: High pressure vaporizers with aluminium finned outer tubes and high strength stainless steel inner tubes for gas vaporization through ambient air heat exchange. Available in different sizes and flow capacity for pressure up to 500 bar
4. ELECTRICAL TRIMHEATERS: Electric heaters with power up to 90kW to warm up the gas.
Available in different sizes for pressure up to 420bar.
* The Discharge Gas Control Panel (DGCP) for temperature and pressure control only
* The Buffer Skid for temperature, pressure, and buffer control
3. AMBIENT AIR VAPORIZERS: High pressure vaporizers with aluminium finned outer tubes and high strength stainless steel inner tubes for gas vaporization through ambient air heat exchange. Available in different sizes and flow capacity for pressure up to 500 bar
4. ELECTRICAL TRIMHEATERS: Electric heaters with power up to 90kW to warm up the gas.
Available in different sizes for pressure up to 420bar.
5. GAS FILLING EQUIPMENT: The filling racks can fill batches of 8, 10, 12 or 16 bottles.
The filling racks are composed of:
* An aluminum structure
* A tray supporting the flexible hoses or the lyres (adapted to different cylinder heights)
* A safety cage to protect the operator
The filling racks are composed of:
* An aluminum structure
* A tray supporting the flexible hoses or the lyres (adapted to different cylinder heights)
* A safety cage to protect the operator
6. Liquid Filling system: Complete skid with all valves and instruments to fill cylinders in total safety with the highest accuracy. supplies single gas, double mono gas or mixture filling systems and filling skid equipment are CTE or BAM approved for O2 filling and ATEX approved for explosive gases.
7. PLC Control system: PLC system can monitor and control all modules of the cylinder filling stations with integrated secured processes to reduce human errors. All operator panels are user friendly with high quality touch screen.
PLC control systems are available with remote access for a total peace of mind. Full traceability & historian software for reporting, configuration, modular and scalable, recipes builder, multilanguage, link with ERP…
8. Analyzer Cabinet option
PLC control systems are available with remote access for a total peace of mind. Full traceability & historian software for reporting, configuration, modular and scalable, recipes builder, multilanguage, link with ERP…
8. Analyzer Cabinet option
Specification
Cryogenic Pump parameter | ||
Working Temperature (degree): | - 196 | |
Working Medium | LOX, LIN, LAr | |
Inlet Pressure (Mpa): | 0.05 ~ 1.6 Mpa | |
Outlet Pressure (Mpa) | 0 ~ 25 Mpa (30 Mpa, 35 Mpa option) | |
Flow (L/h): | 300~ 600 L/H; 400~ 800 l/h; 500~ 1000 l/h | |
Power (Kw): | 5~22 kw | |
Speed Regulation: | Frequency Control | |
Filling station Specification | ||
Applications | Cylinder and buffer tank filling | |
Liquids pumped | LOX, LIN, LAr, LCO2 , LN2 O, LNG | |
Parameter | Single gas, double mono gas or mixture filling systems | |
Design pressure | 420 bar / 6100 PSI | |
Design pressure | 280 bar / 4000 PSI | |
